CP-UVR-0401L1-4KI2 DVR for CCTV is available at Chandra Store, a trusted electronics and CCTV dealer based in Jamalpur, Munger district, Bihar. It is a DVR (digital video recorder), part of our DVR Recorders range. We supply genuine, tested units with manufacturer warranty and support customers across Munger, Jamalpur and other cities of Bihar with fast delivery and after-sales help.
CP-UVR-0401L1-4KI2 DVR for CCTV — Full Specifications
| Processor | Embedded Processor |
|---|---|
| Operating System | Embedded Linux |
| IP Camera Input | 4 + 4 channels, with each channel supporting up to 8MP |
| Two-Way Talk | Audio input/output reuse, RCA |
| User Interface | GUI |
| Video Output | 1 × HDMI, 1 × VGA |
| Video Resolution – HDMI | 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Video Resolution – VGA | 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Video Recording – Main Stream | 4K @ 1–10fps, 6MP @ 1–10fps, 5MP @ 1–12fps, 4K-N, 4MP/3MP @ 1–15fps, 4M-N/1080P/720P/960H/D1/CIF @ 1–25/30fps |
| Video Recording – Sub Stream | 960H @ 1–15fps, D1/CIF @ 1–25/30fps |
| Supported Resolutions | 4K, 6MP, 5MP, 4K-N, 4MP, 3MP, 4M-N, 1080P, 720P, 960H, D1, CIF |
| Video Compression | AI Coding, H.265+, H.265, H.264+, H.264 |
| Video Display Split | 4 / 5 / 6 |
| Video Channel | 4 channels, BNC |
| Audio Compression | G.711A, G.711U, PCM |
| Audio Output | 1 channel, RCA |
| Audio Input | 1 channel, RCA |
| Motion Detection | 396 MD zones (22 × 18) |
| Video Loss Detection | Supported |
| Smartphone Support | iPhone, iPad and Android phones |
| Face Recognition | Processes up to 8 face pictures/sec across 2 video channels; supports analog cameras only |
| Stranger Mode | Detects faces not present in the device database with manually adjustable similarity threshold |
| Hard Disk | 1 × SATA port, supports up to 10TB capacity |
| Face Database Management | Up to 10 face databases with 10,000 face images in total |
| Face Database Information | Name, gender, birthday, address, certificate type, certificate number, country/region and state |
| Bit Rate | 32 Kbps–6144 Kbps per channel |
| Trigger Events | Recording, PTZ, tour, video push, email, FTP, snapshot, buzzer and screen tips |
| Database Application | Each database can be independently applied to video channels |
| Recording Mode | Manual, Schedule, General, Continuous, Motion Detection, Video Loss, Tampering, Alarm and Stop |
| Search Mode | Time/Date, Alarm, Motion Detection and Exact Search accurate to the second |
| Backup Mode | USB Device / Network |
| Playback Functions | Play, Pause, Stop, Rewind, Fast Play, Slow Play, Next/Previous File, Next/Previous Camera, Full Screen, Repeat, Shuffle, Backup, Selection and Digital Zoom |
| Maximum User Accounts | 128 users |
| Record Interval | 1–60 minutes (default: 60 minutes) |
| Pre-Record | 1–30 seconds |
| Post-Record | 10–300 seconds |
| Ethernet | 1 × RJ-45 port, 1000Mbps |
| Interface Ports | 2 × USB 2.0, 1 × RS485 |
| Network Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P, IP Search, ONVIF 16.12, CGI Conformant |
| Power Supply | DC 12V / 2A |
| Power Consumption | <10W (without HDD) |
| Operating Temperature | -10°C to +55°C (+14°F to +131°F) |
| Operating Humidity | 0–90% RH |
| Dimensions (W × D × H) | 260 × 238 × 48 mm |
| Weight | 1.1 kg (without HDD) |
Frequently Asked Questions (FAQs)
What is the CP-UVR-0401L1-4KI2 DVR for CCTV?
It is a DVR (digital video recorder) sold by Chandra Store, suited for home, office and business use.
How many camera channels does the CP-UVR-0401L1-4KI2 DVR for CCTV support?
Channel capacity depends on the model — contact us for exact specifications.
Does the CP-UVR-0401L1-4KI2 DVR for CCTV come with a warranty?
Yes, it comes with manufacturer warranty and after-sales support from Chandra Store.
Is the CP-UVR-0401L1-4KI2 DVR for CCTV available in Munger and other cities of Bihar?
Yes, Chandra Store delivers the CP-UVR-0401L1-4KI2 DVR for CCTV to Munger, Jamalpur and other cities and districts across Bihar, with in-store pickup also available.
Where can I buy the CP-UVR-0401L1-4KI2 DVR for CCTV at the best price?
You can buy it directly from Chandra Store in Jamalpur, Munger, either in-store or online, with genuine products and competitive pricing. For more background, see the manufacturer’s official website on the brand.
Where can I buy the CP-UVR-0401L1-4KI2 DVR for CCTV in Munger and other cities of Bihar?
You can buy the CP-UVR-0401L1-4KI2 DVR for CCTV directly from Chandra Store in Jamalpur, Munger — browse our full DVR Recorders range online, or visit our store for a hands-on demo and installation support.
