CP-UVR-0401E1-IC DVR for CCTV

Original price was: ₹6,999.00.Current price is: ₹4,500.00.

& Free Shipping

Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Max 5 channels IP camera inputs, each channel up to 2MP; Max 20Mbps Incoming Bandwidth
Supports Full-channel AI-Coding
Instastream/H.265 dual-stream video compression
Up to 4 channels video stream (analog channel) SMD Plus.
Support 1 SATA HDD up to 6TB, 2 USB Ports
1 HDMI / 1 VGA Simultaneous Video Output
Mobile Software: iCMOB, gCMOB
CMS Software: KVMS Pro

SKU: PDT_77939 Categories: DVR Recorders, Shop Tag: dvr Brand: CP Plus

Guaranteed Safe Checkout

Description
Reviews (0)

Processor	Embedded Processor
Operating System	Embedded Linux
IP Camera Input	4 + 1 channels, with each channel supporting up to 2MP
Two-Way Talk	Audio input/output reuse, RCA
User Interface	GUI
Video Output	1 × HDMI, 1 × VGA
Video Output Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
Video Recording – Main Stream	All channels: 1080N/720P/960H/D1/CIF @ 1–25/30fps
Video Recording – Sub Stream	CIF @ 1–15fps
Video Compression	AI Coding, H.265+, H.265, H.264+, H.264
Video Display Split	4 / 5 / 6
Video Channel	4 channels, BNC
Audio Compression	G.711A, G.711U, PCM
Audio Output	1 channel, RCA
Audio Input	1 channel, RCA
Motion Detection	396 MD zones (22 × 18)
Video Loss Detection	Supported
Bit Rate	32 kbps–4096 kbps per channel
Smartphone Support	iPhone, iPad and Android phones
Hard Disk Support	1 × SATA port, supports up to 6TB
Camera Blank	Supported
Trigger Events	Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Recording Mode	Manual, Schedule, Regular, Continuous, Motion Detection, Video Loss, Tampering, Alarm and Stop
Search Mode	Time/Date, Alarm, Motion Detection and Exact Search accurate to the second
Backup Mode	USB Device / Network
Playback Functions	Play, Pause, Stop, Rewind, Fast Play, Slow Play, Next/Previous File, Next/Previous Camera, Full Screen, Repeat, Shuffle, Backup, Selection and Digital Zoom
Maximum User Accounts	128 users
Record Interval	1–60 minutes (default: 60 minutes)
Pre-Record	1–30 seconds
Post-Record	10–300 seconds
Ethernet	1 × RJ-45 port, 100Mbps
Interface Ports	2 × USB 2.0
Network Protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, 3G/4G, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, InstaOn, IP Search, ONVIF 16.12, CGI Conformant
Power Supply	DC 12V / 1.5A
Power Consumption	<7W (without HDD)
Operating Temperature	-10°C to +45°C (+14°F to +113°F)
Operating Humidity	10–90% RH
Dimensions (W × D × H)	198 × 203.0 × 41.5 mm
Weight	0.57 kg (without HDD)
