Name: CP-UVR-0801L1-4KV2 DVR for CCTV
Brand: CP Plus
SKU: PDT_11246
Price: 6250.00 INR
Availability: OutOfStock

CP-UVR-0801L1-4KV2 DVR for CCTV

₹6,250.00

& Free Shipping

Support HDCVI/AHD/TVI/CVBS/IP video inputs
Max 12 channels IP camera inputs, each channel up to 6MP
Max 48Mbps Incoming Bandwidth
HDMI / VGA Simultaneous Video Output
Support 1 SATA HDD up to 8TB, 2 USB Port
Mobile Software: iCMOB, gCMOB
CMS Software:KVMS, KVMS Pro

Out of stock

SKU: PDT_11246 Categories: DVR Recorders, Shop Tag: dvr Brand: CP Plus

Guaranteed Safe Checkout

Compare

Processor	Embedded Processor
Operating System	Embedded Linux
IP Camera Input	8 + 4 channels; each channel supports up to 6MP
Two-Way Talk	Audio input/output reuse, RCA
User Interface	GUI
Video Output	1 × HDMI, 1 × VGA
Video Resolution	HDMI: 3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 1024, 1280 × 720, 1024 × 768; VGA: 1920 × 1080, 1280 × 1024, 1280 × 720, 1024 × 768
Video Recording	Main Stream: 4K @ 1–7fps, 5MP @ 1–12fps, 4MP/3MP @ 1–15fps, 1080P/720P/960H/D1/CIF/QCIF @ 1–25/30fps; Sub Stream: 960H @ 1–15fps, D1/CIF/QCIF @ 1–25/30fps
Video Display Split	1 / 4 / 8 / 9
Video Channel	8 channels, BNC
Video Standard	NTSC, PAL
Audio Output	1 channel, RCA
Audio Channel	1 channel, RCA
Motion Detection	396 MD zones (22 × 18)
Video Loss	Supported
Smartphone Support	iPhone, iPad and Android phones
Hard Disk Support	1 × SATA port, up to 8TB
Trigger Events	PTZ, Tour, Video Push, Recording, Email, FTP, Snapshot, Buzzer and Screen Tips
Recording Mode	Manual, Schedule (Regular, Continuous), MD (Motion Detection, Video Loss, Tampering), Alarm and Stop
Search Mode	Time/Date, Alarm, Motion Detection and Exact Search accurate to the second
Backup Mode	USB Device / Network
Playback	Play, Pause, Stop, Rewind, Fast Play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup, Selection and Digital Zoom
Maximum User Accounts	128 users
Record Interval	1–60 minutes (default: 60 minutes)
Pre-Record	1–30 seconds
Post-Record	10–300 seconds
Ethernet	1 × RJ-45 port, 1000M
Interface Ports	1 × USB port (USB 2.0/USB 3.0), 1 × RS485 port for PTZ control
Network Protocols	HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P, ONVIF 2.42, CGI
Power Supply	DC 12V / 2A
Power Consumption	<10W (without HDD)
Working Temperature	-10°C to +60°C
Working Humidity	0–90% RH
Dimensions	260 × 236 × 48 mm
Weight	0.75 kg (without HDD)
