| Processor | Embedded Processor |
|---|---|
| Operating System | Embedded Linux |
| IP Camera Input | 8 + 2 channels, with each channel supporting up to 6MP |
| Two-Way Talk | Audio input/output reuse, RCA |
| User Interface | GUI |
| Video Output | 1 × HDMI, 1 × VGA |
| Video Input | 8 channels, BNC |
| Video Compression | InstaStream, H.265, H.264+, H.264 |
| Video Display Split | 1 / 4 / 8 / 9 |
| Video Loss Detection | Supported |
| Video Recording – Main Stream | 1st channel: 1080N/720P @ 1–25/30fps; Other channels: 1080N/720P @ 1–15fps; 960H/D1/CIF @ 1–25/30fps |
| Video Recording – Sub Stream | CIF/QCIF @ 1–7fps |
| Video Output Resolution | 1920 × 1080, 1280 × 1024, 1280 × 720, 1024 × 768 |
| Supported Recording Resolution | 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
| Bit Rate | 32 kbps–4096 kbps per channel |
| Audio Compression | G.711A, G.711U, PCM |
| Audio Input | 1 channel, RCA |
| Audio Output | 1 channel, RCA |
| Audio Sample Rate | 8 kHz, 16-bit per channel |
| Audio Bit Rate | 64 kbps per channel |
| Record Interval | 1–60 minutes (default: 60 minutes) |
| Pre-Record | 1–30 seconds |
| Post-Record | 10–300 seconds |
| Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| OSD Information | Camera title, time, video loss, camera lock, motion detection and recording |
| Motion Detection | Supported |
| Playback Channels | 1 / 4 / 9 channels |
| Camera Blank | Supported |
| Playback Functions | Play, Pause, Stop, Rewind, Fast Play, Slow Play, Next/Previous File, Next/Previous Camera, Full Screen, Repeat, Shuffle, Backup, Selection and Digital Zoom |
| Search Mode | Time/Date, Alarm, Motion Detection and Exact Search accurate to the second |
| Recording Mode | Manual, Schedule, Regular, Continuous, Motion Detection, Video Loss, Tampering, Alarm and Stop |
| Backup Mode | USB Device |
| Hard Disk | 1 × SATA port, supports up to 6TB capacity |
| User Accounts | 128 users |
| Smartphone Support | iPhone, iPad and Android phones |
| Ethernet | 1 × RJ-45 port, 100Mbps |
| Interface Ports | 2 × USB 2.0 ports |
| Network Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, DDNS, FTP, Alarm Server, InstaOn, IP Search, ONVIF 16.12, CGI Conformant |
| Power Supply | DC 12V / 1.5A |
| Power Consumption | <10W (without HDD) |
| Operating Temperature | -10°C to +45°C (+14°F to +113°F) |
| Operating Humidity | 10–90% RH |
| Storage Temperature | -20°C to +70°C (-4°F to +158°F) |
| Storage Humidity | 0–90% RH |
| Dimensions (W × D × H) | 198 × 202.9 × 41.5 mm |
| Net Weight | 0.55 kg (without HDD) |
Sale!
DVR Recorders, Shop
CP-UVR-0801E1-CV4 DVR for CCTV
Original price was: ₹4,999.00.₹4,500.00Current price is: ₹4,500.00.
& Free Shipping- Supports HDCVI/AHD/TVI/CVBS/IP video inputs
- Max 10 channels IP camera inputs, each channel up to 6MP; Max 40Mbps Incoming Bandwidth
- Support 1 SATA HDD up to 6TB, 2 USB Ports
- 1 HDMI / 1 VGA Simultaneous Video Output
- Instastream/H.265/H.264+/H.264 video compression
- Mobile Software: iCMOB, gCMOB
- CMS Software: KVMS Pro
Out of stock
