CP-UVR-0801L1-4KI3-V2 DVR for CCTV is available at Chandra Store, a trusted electronics and CCTV dealer based in Jamalpur, Munger district, Bihar. It is a DVR (digital video recorder), part of our DVR Recorders range. We supply genuine, tested units with manufacturer warranty and support customers across Munger, Jamalpur and other cities of Bihar with fast delivery and after-sales help.
CP-UVR-0801L1-4KI3-V2 DVR for CCTV — Full Specifications
| Processor | Industrial-grade Processor |
|---|---|
| Operating System | Embedded Linux |
| IP Camera Input | Up to 16 IPC channels; 8 IP channels by default + 8 channels through analog-to-IP conversion |
| Network Bandwidth | 128 Mbps incoming, 128 Mbps recording and 128 Mbps outgoing bandwidth |
| AI Function Limitation | Adding IP channels beyond the existing channels disables IVS, SMD and Face AI functions |
| CVI Camera Input | 4K @ 25/30fps, 6MP @ 20fps, 5MP @ 20/25fps, 4MP @ 25/30fps, 1080p @ 25/30fps, 720p @ 25/30/50/60fps |
| TVI Camera Input | 4K @ 15fps, 5MP @ 20fps, 4MP @ 25/30fps, 3MP @ 25/30fps, 1080p @ 25/30fps, 720p @ 25/30fps |
| AHD Camera Input | 4K @ 15fps, 5MP @ 20fps, 4MP @ 25/30fps, 3MP @ 25/30fps, 1080p @ 25/30fps, 720p @ 25/30fps |
| Two-Way Talk | Supported; shares the same audio input with the first channel |
| User Interface | Web, Local GUI |
| SMD Plus by DVR | 8 channels with secondary human and motor vehicle filtering to reduce false alarms |
| Perimeter AI Performance | Advanced Model: 2 channels, 10 IVS per channel; General Model: 8 channels, 10 IVS per channel |
| Face Attributes | Gender, age group, glasses, expressions, face mask and beard |
| Face Detection Performance | 2 channels, up to 12 face images per channel |
| Video Input | 8 channels, BNC |
| Video Output | 1 × HDMI, 1 × VGA |
| HDMI Output Resolution | 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 |
| VGA Output Resolution | 1920 × 1080, 1280 × 1024, 1280 × 720 |
| HDMI / VGA Output | Simultaneous and heterogeneous video source output is configurable |
| Video Compression | H.265+, Smart H.264+, H.264 |
| Encoding Strategy | AI InstaStream, InstaStream |
| Video Streaming – Main Stream | 4K @ 1–7fps, 6MP @ 1–10fps, 5MP @ 1–12fps, 4K-N/4MP/3MP @ 1–15fps, 4M-N/1080p/720p/960H/D1/CIF @ 1–25/30fps |
| Video Streaming – Sub Stream | 960H @ 1–15fps, D1/CIF @ 1–25/30fps |
| Video Display Split | 1 / 4 / 8 / 9 |
| Audio Input | 1-channel RCA, 8-channel BNC (Coaxial Audio) |
| Bit Rate | 32 kbps–6144 kbps |
| Audio Output | 1 channel, RCA |
| Audio Sample Rate | 8 kHz, 16-bit per channel |
| Audio Bit Rate | 64 kbps per channel |
| Audio Compression | G.711A, G.711U, PCM |
| General Alarm | Motion detection, video loss and tampering |
| Alarm Linkage | Record, panoramic snapshot, IPC external alarm output, access controller, voice prompt, buzzer, log, preset and email |
| Smartphone Support | iPhone, iPad and Android phones |
| Hard Disk Support | 1 × SATA port, up to 16TB capacity; maximum capacity varies with ambient temperature |
| Recording Modes | General, Motion Detection, Intelligent, Alarm and POS |
| Recording Playback | Instant playback, general playback, event playback, tag playback and smart playback |
| Smart Playback | Face detection and motion detection |
| Backup Mode | USB Device / Network |
| Interface Ports | 2 USB ports (1 × front USB 2.0, 1 × rear USB 3.0), 1 × RS485 |
| Browser Support | Chrome, Internet Explorer 9 or later, Firefox |
| Network Mode | Single-address mode |
| Ethernet | 1 × RJ-45 Ethernet port, 10/100/1000 Mbps |
| Network Protocols | IPv4/IPv6, HTTP, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPoE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0 |
| Power Supply | DC 12V / 2A |
| Power Consumption | <10W (without HDD) |
| Operating Humidity | 10%–90% RH |
| Operating Temperature | -10°C to +55°C (+14°F to +131°F) |
| Dimensions (W × D × H) | 260.0 × 237.9 × 47.6 mm |
Frequently Asked Questions (FAQs)
What is the CP-UVR-0801L1-4KI3-V2 DVR for CCTV?
It is a DVR (digital video recorder) sold by Chandra Store, suited for home, office and business use.
How many camera channels does the CP-UVR-0801L1-4KI3-V2 DVR for CCTV support?
It supports 8 channels, BNC.
Does the CP-UVR-0801L1-4KI3-V2 DVR for CCTV come with a warranty?
Yes, it comes with manufacturer warranty and after-sales support from Chandra Store.
Is the CP-UVR-0801L1-4KI3-V2 DVR for CCTV available in Munger and other cities of Bihar?
Yes, Chandra Store delivers the CP-UVR-0801L1-4KI3-V2 DVR for CCTV to Munger, Jamalpur and other cities and districts across Bihar, with in-store pickup also available.
Where can I buy the CP-UVR-0801L1-4KI3-V2 DVR for CCTV at the best price?
You can buy it directly from Chandra Store in Jamalpur, Munger, either in-store or online, with genuine products and competitive pricing. For more background, see the manufacturer’s official website on the brand.
Where can I buy the CP-UVR-0801L1-4KI3-V2 DVR for CCTV in Munger and other cities of Bihar?
You can buy the CP-UVR-0801L1-4KI3-V2 DVR for CCTV directly from Chandra Store in Jamalpur, Munger — browse our full DVR Recorders range online, or visit our store for a hands-on demo and installation support.
