CP-UVR-0801F1-IC2 DVR for CCTV

₹6,450.00

& Free Shipping

Up to 8 Ch IP Camera Input
Max 12 channels IP camera inputs, each channel up to 6MP
Max 64Mbps Incoming Bandwidth
Supports Full-channel AI Instastream
1 HDMI / 1 VGA Simultaneous Video Output
Support 1 SATA HDD up to 16TB Each, 2 USB Ports
Up to 8 channels video stream (analog channel) SMD Plus
Mobile Software: iCMOB, gCMOB
CMS Software: KVMS Pro Lite

SKU: PDT_18196 Categories: DVR Recorders, Shop Tag: dvr Brand: CP Plus

Guaranteed Safe Checkout

Description
Reviews (0)

Processor	Industrial-grade processor
Operating System	Embedded Linux
Analog Camera Input	8 channels, BNC; adaptive HDCVI, AHD, TVI and CVBS access
Camera Input – CVI	5MP, 4MP, 1080p @ 25/30fps, 720p @ 50/60fps, 720p @ 25/30fps
Camera Input – TVI	5MP, 4MP, 1080p @ 25/30fps, 720p @ 25/30fps
Camera Input – AHD	5MP, 4MP, 1080p @ 25/30fps, 720p @ 25/30fps
Camera Input – CVBS	PAL / NTSC
IP Camera Input	Up to 12 IPC channels; 4 IP channels by default + 8 channels through analog-to-IP conversion
Network Bandwidth	64 Mbps incoming, 64 Mbps recording and 64 Mbps outgoing bandwidth
IP Extension Mode	Adding IP channels beyond existing channels disables the AI SMD function
User Interface	Web, GUI
Video Input	8 channels, BNC
Video Output	1 × HDMI, 1 × VGA
HDMI / VGA Resolution	1920 × 1080, 1280 × 1024, 1280 × 720
SMD Plus	8-channel secondary filtering for humans and motor vehicles to reduce false alarms from leaves, rain and lighting changes
Video Compression	H.265+, H.264+, H.264
Encoding Capacity – Main Stream	5M-N @ 1–10fps; 4M-N/1080p @ 1–15fps; 1080N/720p/960H/D1/CIF @ 1–25/30fps
Encoding Capacity – Sub Stream	D1/CIF @ 1–15fps
Encoding Strategy	AI InstaStream, InstaStream
Network Mode	Single-address mode
Video Display Split	1/4/8/9/16; with IP extension mode: 1/4/8/9/16
Bit Rate	32 kbps–6144 kbps
Audio Compression	G.711A, G.711U, PCM
Smartphone Support	iPhone, iPad and Android phones
Audio Sample Rate	8 kHz, 16-bit per channel
Audio Bit Rate	64 kbps per channel
General Alarm	Motion detection, video loss and tampering
Alarm Linkage	Recording, panoramic snapshot, local alarm output, IPC external alarm output, access controller, audio, buzzer, log, preset and email
Browser Support	Chrome, Internet Explorer 9 or later, Firefox
Recording Playback	Instant playback, general playback, event playback and tag playback
Playback Channels	1/4/8/9 channels
Backup Mode	USB device / Network
USB Ports	2 × USB 2.0
Ethernet	1 × 10/100 Mbps Ethernet port, RJ-45
Network Protocols	HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, FTP, ONVIF 21.06, CGI Conformant
Power Supply	DC 12V / 15A
Power Consumption	<7W
Operating Temperature	–10°C to +55°C (+14°F to +131°F)
Operating Humidity	0%–90% RH
Dimensions (W × H × D)	198.3 × 203.4 × 41.5 mm
Weight	0.57 kg without HDD
