CP Plus 4CH DVR CP-UVR-0401E1-CV5

₹2,899.00

& Free Shipping

Supports HDCVI, AHD, TVI, CVBS, and IP camera video inputs.
Supports up to 5 IP camera channels with resolutions up to 2MP per channel.
20 Mbps maximum incoming bandwidth for smooth video recording.
Supports 1 SATA hard drive with storage capacity up to 6TB.
Equipped with 2 USB ports for backup and peripheral connectivity.
HDMI and VGA outputs support simultaneous display.
Advanced InstaStream, H.265, H.264+, and H.264 video compression for efficient storage.
Remote monitoring via iCMOB and gCMOB mobile applications.
Compatible with KVMS Pro CMS software for centralized surveillance management.

Out of stock

SKU: PDT_24121 Categories: DVR Recorders, Shop Tag: dvr Brand: CP Plus

Guaranteed Safe Checkout

Description
Reviews (0)

Processor	Embedded processor
Operating System	Embedded LINUX
IP Camera Input	4+1, each channel up to 2MP
Two-way Talk	Reuse audio in/out, RCA
User Interface	GUI
Video Input	4 channel, BNC
Video Output	1 HDMI, 1 VGA
Video Compression	Instastream/H.265+/H.264+/H.264
Video Resolution	1920×1080, 1280×1024, 1280×720
Video Recording	Main Stream: All channels 1080N/720P/960H/D1/HD1/BCIF/CIF/ QCIF(1~25/30fps); Sub stream: CIF/QCIF (1~15fps)
Resolution	1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF
Video Display Split	1/4
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Bit Rate	32 kbps–4096 kbps per channel
Audio Compression	G.711A, G.711U, PCM
Audio Input	1 channel, RC
Audio Output	1 channel, RC
Audio Sample Rate	8KHz, 16 bit Per Channel
Audio Bit Rate	64Kbps Per Channel
Camera Blank	Support
Smart Phone	iPhone, iPad, Android Phone
Hard Disk	1 SATA port, up to 6TB capacity
Trigger Events	Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Recording Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Search Mode	Time/Date, Alarm, MD & Exact search (accurate to second)
Playback	1/4Ch.
Playback Function	Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom
Backup Mode	USB Device/Network
Interface Ports	2 USB Ports (USB 2.0)
User Access	128 users
Record Interval	1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Ethernet	1 RJ-45 port (100Mbps)
Protocols	HTTP; TCP/IP; IPv4/IPv6; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; P2P; IP Search, ONVIF 16.12, CGI Conformant
Power Supply	DC12V/1.5A
Working Temperature	-10°C ~ +45°C (+14°F ~ +113°F), 10 ~ 90% (RH)
Power Consumption	<10W (without HDD)
Storage Temperature	-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% (RH)
Dimension	197mm×192mm×41mm (7.8“×7.6”×1.6“)
Net Weight	0.56kg (without HDD)
